Zoom Audio Recorders & Accessories>AMS-24 USB-C Audio Interface

Zoom Audio Recorders & Accessories>AMS-24 USB-C Audio Interface

$188.26

SKU: SKUZYJfbeiAQA Categories: Audio, Audio By Type, Audio Recorders & Accessories Tag: Zoom Brand: Zoom

Description
Reviews (0)

Key Features:

Musicians, Podcasters, and Streamers
AC and Bus Powered, Mac/Windows, Mobile
Hi-Z and 2 Mic/Line Preamp Inputs
Stereo Line Output, 2 Headphone Outputs
24-Bit / 96 kHz AD/DA Conversion
48V, Zero-Latency Monitoring
Loopback for Streaming
iOS/Android Compatible

Zoom AMS-24 USB-C Audio Interface

Designed for musicians who need a portable and flexible solution, the Zoom AMS-24 is a compact USB-C audio interface that makes recording and streaming easy on Mac, Windows, iOS, and Android devices. It features two TRS/XLR combo inputs, two TRS outputs, dual headphone jacks, and dedicated modes for both streaming and recording, offering a streamlined setup that’s perfect for creating high-quality audio content on the go.

Channels of I/O	Analog:
	2 Inputs / 2 Outputs
Maximum Sampling Rate	96 kHz / 24-Bit
Number of Microphone Inputs	2
Input Level Adjustment	2x Knob
Gain/Trim Range	+8 to +54 dB

CONNECTIVITY

Analog Audio I/O	Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
	Combo XLR-1/4″ TRS Balanced/Unbalanced Mic/Line Input
	1/4″ TRS Balanced Line Output
Phantom Power	48 V, Selectable On/Off
Host Connection	USB-C
Host Connection Protocol	USB 2.0

PERFORMANCE

Frequency Response	20 Hz to 20 kHz +0/-2 dB (at 44.1 kHz)
	20 Hz to 40 kHz +0/-3 dB (at 96 kHz)
Maximum Input Level	Combo XLR-1/4″ Mic Inputs:
	+6 dBu
	Combo XLR-1/4″ Line Inputs:
	+22 dBu
	Hi-Z:
	+8.5 dBu
Maximum Output Level	1/4″ Line Outputs:
	+10 dBu at 0 dBFS
Headphone Output Power	1/8″ / 3.5 mm:
	30 mW per Channel into 32 Ohms
Impedance	Mic Inputs:
	2.7 Kilohms
	Line Inputs:
	18 Kilohms
	Line Outputs:
	100 Ohms
	Hi-Z Inputs:
	330 Kilohms
	Headphone Outputs:
	10 Ohms
EIN	≤ -120 dBu (150-Ohm Source)
Sample Rates	44.1 / 48 / 88.2 / 96 kHz
Bit Depths	24-Bit
OS Compatibility	Windows / macOS
OS Compatibility	Windows
	macOS

POWER

Battery Type	AA
Approximate Battery Life	4 Hours (Alkaline, 32-Ohm Load, Phantom Off)

PHYSICAL

Dimensions	9.4 x 7.4 x 4.6 cm
Weight	0.134 kg

* Specifications subject to change by the manufacturer without notice.

Zoom AMS-24 USB-C Audio Interface
USB-C Cable
