Sale!

PortKeys Video Monitors & Accessories>HS8 8" 3G-SDI 4K HDMI/3G-SDI High-Bright Monitor with 3D LUT Support

PortKeys Video Monitors & Accessories>HS8 8″ 3G-SDI 4K HDMI/3G-SDI High-Bright Monitor with 3D LUT Support

Original price was: $928.56.Current price is: $174.90.

SKU: SKUdb7IDVZJAk Categories: Pro Video, Video Accessories, Video Monitors & Accessories Tag: PortKeys Brand: PortKeys

Description
Reviews (0)

Key Features:

8″ HDMI & 3G-SDI 1920 x 1200 Monitor
Supports up to DCI 4K24 Input
1100 cd/m² Bright, 1000:1 Contrast Ratio
10-Bit Color, 3D LUT Out on HDMI & SDI

Portkeys HS8 8″ 3G-SDI 4K HDMI/3G-SDI High-Bright Monitor with 3D LUT Support

Experience accurate monitoring with the PORTKEYS HS8 8″ 3G-SDI 4K HDMI/3G-SDI High-Bright Monitor, designed to support up to DCI 4K24 video with a crisp 1920 x 1200 resolution, 10-bit colour depth, and 3D LUT output via both 4K HDMI and 3G/HD/SD-SDI connections. With a high brightness level of 1100 cd/m², it’s well suited for outdoor use, while its 178° wide viewing angle allows multiple crew members to view footage simultaneously. The rear panel includes a detachable cover for installing a video transmitter and dual Sony L-series/NP-F battery plates for versatile power options.

HDMI and 3G-SDI Input/Output

4K HDMI and 3G/HD/SD-SDI inputs, both with loop-through outputs

3D LUT Support

3D LUTs for colour grading and monitoring can be applied to both the HDMI and SDI outputs

Hi-Bright Monitor

8″ on-camera monitor with 1100 cd/m² brightness and 1000:1 contrast ratio

Durable Housing

Rugged, heat-dissipating CNC-machined aluminium alloy housing

Top and bottom 1/4″-20 thread mounts

Hot-Swappable Battery Plates

Hot-swappable, dual Sony L-series-type battery plates

DC input port for power supply

Optional Wireless Video Transmitter

Comes with a detachable cover for the wireless video transmitter mount

DISPLAY

Panel Type	LCD
Display Size	8.0″ / 20.3 cm
Native Resolution	1920 x 1200
Aspect Ratio	0.672916667
Viewing Angle	Horizontal: 178°
	Vertical: 178°
Maximum Brightness	1100 nits / cd/m2
Contrast Ratio	41.66736111
Colour Support	1.07 Billion Colours (8-Bit+FRC)
HDR Support	Yes
Colour Gamut	100% Rec. 709
LUT Support	Yes
Image Controls	Anamorphic De-Squeeze, Blue Only, Check Field, Colour Temperature Selection, Customisable Aspect Ratios, False Colour, Focus Peaking, Green Only, Histogram, Image Flip, OSD Flip, Red Only, RGB Parade, Screen Markers, Vectorscope, Waveform, Zebra

INPUTS/OUTPUTS

Video I/O	1x BNC (3G-SDI) Input
	1x HDMI (Unspecified Signal) Input
	1x BNC (3G-SDI) Output
	1x HDMI (Unspecified Signal) Output
Embedded Audio	HDMI
	SDI
Audio I/O	1x 1/8″ / 3.5 mm Headphone Output
Power I/O	1x Barrel (20 VDC) Input
Other I/O	1x USB-A (LUT Upload)

FORMAT SUPPORT

Video Format	HDMI
	DCI 4K: 60/59.94/50/30/29.97/25/24/23.98
	UHD 4K: 60/59.94/50/30/29.97/25/24/23.98
	1080p: 60/59.94/50/30/29.97/25/24/23.98
	1080PsF: 30/29.97/25/24/23.98
	1080p: 60/59.94/50/30/29.97/25/24/23.98
	1080PsF: 30/29.97/25/24/23.98
	1080i: 60/59.94/50
	720p: 60/59.94/50
	SDI (4:2:2 YUV)
	1080p: 60/59.94/50/30/29.97/25/24/23.98
	SDI (4:4:4/4:2:2/4:2:0 RGB, YUV)
	1080PsF: 30/29.97/25/24/23.98
	SDI (4:4:4/4:2:2)
	1080i: 60/59.94/50
	720p: 60/59.94/50
Video Signal Conversion	HDMI to SDI

	SDI to HDMI

POWER

Input Power	7 to 20 VDC
Battery	2x L-Series Mount on Fixed Plate
Power Consumption	20 W (Maximum)
MOUNTING
VESA Mounting-Hole Pattern	100 x 100 mm
Tripod/Accessory Mounting	2x 1/4″-20 Female
GENERAL
Material of Construction	Aluminium
Dimensions	208 x 133.7 x 50.5 cm
Weight	0.675 Kg

* Specifications subject to change by the manufacturer without notice.

PORTKEYS HS8 8″ 3G-SDI 4K HDMI/3G-SDI High-Bright Monitor with 3D LUT Support
D-Tap to DC Barrel Power Cable
Screen Cleaning Cloth
M2 Allen Key
M3 Allen Screw
Cup Head Gasket
Micro-USB Flash Drive
