IDX Battery Chargers & Plates>System Technology DUO-C150P 145Wh High-Load Li-Ion V-Mount Battery

IDX System Technology Endura DUO-CP Overview

Power up your professional V-mount cameras such as the RED WEAPON or ARRI ALEXA Mini, as well as other professional devices with this DUO-C150P 145Wh High-Load Li-Ion V-Mount Battery from IDX System Technology. This compact battery is only 2.3″ thick, but packs a large 145Wh, 9.9Ah capacity, providing 14.5V to your gear with a 14A maximum draw. Perfect for digital cinema cameras and camera stabilizer systems where long runtimes are needed, the battery data information displays in most cameras’ viewfinders.

The DUO-C150P can output power via its V-mount, two D-Tap outputs, and USB Type-C port. One of the D-Tap ports is an Advanced port that can also be used to charge the battery with an optional D-Tap charger such as the UC-PD1. The USB Type-C is also a PD Fast Charging input that allows you to fast-charge the battery using up to 60W.

Designed with battery circuit protection against overcharge, overdischarge, overcurrent, and exposure to high temperatures, it protects your battery from the rigors of production. A 5-LED battery life indicator on its side provides a quick visual indication of the charge state of your battery, and its housing is designed with antimicrobial, antiviral materials.

Features

• Suitable for cinema camera productions that need a high-capacity battery in a small package
• The battery data displays in the viewfinder system of most cameras, and the addition of an SMBus enables RED cameras to display this information as well
• V-Torch light for easy attachment to the plate
• Handles up to 14A loads
• Two unregulated D-Tap accessory outputs at 80W each, one is a D-Tap Advanced input to also charge the battery
• USB Type-C output port with 60W PD fast charging input
• Battery circuit protection including over-charge, over-discharge, over-current, and over-temperature
• 5-LED battery life indicator
• Fully compatible with all IDX Endura V-mount chargers, as well as the UC-PD1 USB Type-C charger and the VL-DT1 D-Tap charger
• Antiviral and antimicrobial body for hygienic peace of mind
